ATC200, ATC200M and ATC200S Technical Data
by
Published on 03-09-2010 05:52 PM
Often exclaimed Honda's most popular and widest spread unit in their early ATV line, the ATC200 models are the bread and butter on the ATC heritage. Just about anyone who thinks of a three wheeler has the vision of the ATC200 come to his mind. As follows are the distinct specifications that separated the three main model designations of ATC200, ATC200S and ATC200M.
Honda release several variants of the base ATC200 line excluding the "Big Red" line introduced around the same time. The ATC200 was the result of the natural evolution of the ATC185. A small bump in displacement coupled with the standard creature comfort upgrades provided a steady stream of updated models keeping the ATC line fresh and new without any large changes in the overall design.
Most notable of these variations came in the form of the introduction of hydraulic telescoping forks on the usually suspension-less ATC models. Possibly following in Yamaha's footsteps, the front suspension helped greatly to ease the handling of the non-sport model ATCs. Also worth mentioning is the electric start capability of the ATC200M, possibly a careyover from the "Big Red" version of the ATC200 model.
General ATC200 Specifications| Production Years : |
1981-1983 |
| Engine type : |
4 Stroke, Air cooled |
| Displacement : |
192 cc |
| Bore x Stroke : |
65 x 57.8 mm |
| Compression ratio : |
7.8 to 1 |
| Compression : |
142 - 170 psi |
| Transmission : |
5 speed |
| Clutch Type : |
Semi-auto |
| Oil Capacity : |
1.43 Qt |
| Carburetion : |
22 mm Keihin |
| Starting system : |
Recoil Starter |
| Fuel capacity : |
2.3 Gal , 0.4 Gal res. |
| Wheelbase : |
46.9 in. |
| Overall Length : |
72.4 in. |
| Overall Width : |
42.5 in. |
| Ground Clearance : |
4.9 in. |
| Seat Height : |
27.2 in. |
| Front Tires : |
25 x 12 x 9 |
| Rear Tires : |
25 x 12 x 9 |
| Front Suspension : |
none |
| Rear Suspension : |
none |
| Front Brake : |
lever + cable operated drum |
| Rear Brake : |
pedal operated Drum |
| Final Drive : |
chain |
| Dry Weight : |
299.9 lbs |
| MSRP : |
$1,298.00 |
|
|
General ATC200M Specifications| Production Years : |
1984-1985 |
| Engine type : |
4 Stroke, Air cooled |
| Displacement : |
192cc |
| Bore x Stroke : |
65 x 57.8 mm |
| Compression ratio : |
7.8 to 1 |
| Compression : |
142 - 170 psi |
| Transmission : |
5 speed |
| Clutch Type : |
Semi-auto |
| Oil Capacity : |
1.43 Qt |
| Carburetion : |
22 mm Keihin |
| Starting system : |
Electric with recoil backup |
| Fuel capacity : |
3gal with .03 reserve |
| Wheelbase : |
47.4 in. |
| Overall Length : |
73.0 in. |
| Overall Width : |
42.1 in. |
| Ground Clearance : |
4.7 in. |
| Seat Height : |
27 in. |
| Front Tires : |
25 x 12 x 9 |
| Rear Tires : |
25 x 12 x 9 |
| Front Suspension : |
Hydraulic Telescoping forks |
| Rear Suspension : |
none |
| Front Brake : |
lever + cable operated drum |
| Rear Brake : |
pedal operated Drum |
| Final Drive : |
Chain |
| Dry Weight : |
328 lbs |
| MSRP : |
$1,598.00 |
|
|
General ATC200S Specifications| Production Years : |
1984-1986 |
| Engine type : |
4 Stroke, Air cooled |
| Displacement : |
192 cc |
| Bore x Stroke : |
65 x 57.8 mm |
| Compression ratio : |
7.8 to 1 |
| Compression : |
142 - 170 psi |
| Transmission : |
5 speed |
| Clutch Type : |
Semi-auto |
| Oil Capacity : |
1.43 Qt |
| Carburetion : |
22 mm Keihin |
| Starting system : |
Recoil Starter |
| Fuel capacity : |
2.3 Gal , 0.4 Gal res. |
| Wheelbase : |
46.5 in. |
| Overall Length : |
72.4 in. |
| Overall Width : |
42.5 in. |
| Ground Clearance : |
4.9 in. |
| Seat Height : |
26.8 in. |
| Front Tires : |
22 x 11 x 8 |
| Rear Tires : |
22 x 11 x 8 |
| Front Suspension : |
Hydraulic Telescoping forks |
| Rear Suspension : |
none |
| Front Brake : |
lever + cable operated drum |
| Rear Brake : |
pedal operated Drum |
| Final Drive : |
chain |
| Dry Weight : |
278 lbs |
| MSRP : |
$1,270.00 |
|
|
